Subhadeep Sarkar

Log-structured merge (LSM)-trees are widely used as the storage layer data structure in modern NoSQL key-value stores due to their superior ingestion throughput, competitive query performance, and efficient space utilization. To enable fast ingestion, LSM-based storage engines first batch the incoming data in an in-memory buffer and then, opportunistically write the data to slower secondary storage as a collection of immutable sorted runs. We point out that while the data is largely storage-resident, the overall performance of an LSM-based storage engine is critically bottlenecked by the (i) implementation, (ii) tuning, and (iii) size of the in-memory buffer. In fact, even with the same buffer configuration, the performance of an LSM-engine may vary by several orders of magnitude if there is a shift in workload. Choosing the appropriate buffer design, thus, is crucial for performance, but, at the same time, hard, as the LSM-buffer design space is vast and largely unexplored.
In this paper, we evaluate and analyze the performance of LSM-engines with eleven different buffer implementations – including three hash-hybrid designs – while varying the tuning and size for each implementation to understand their implications on performance and the associated trade-offs. For each configuration, we further vary the workload composition and distribution, the LSM-tuning, and the underlying hardware to quantify their impact on performance. Additionally, we build an Adapt buffer that switches implementation on-the-fly based on the workload shift. To the best of our knowledge, this is the first comprehensive analysis of LSM-buffer design space. Finally, for practitioners, we present a handbook with 10 key guidelines for choosing the appropriate buffer design and tuning for a given workload and performance target.

Zoned Namespace (ZNS) SSDs offer a new storage model that allows for high-throughput and low-latency storage by eliminating device-side garbage collection. The ZNS interface exposes storage as append-only zones, thus requiring host applications (e.g., database systems) to append, read, and garbage collect their pages. However, the ZNS storage abstraction hides the substantial differences across ZNS SSD controller designs. These differences affect both the performance and predictability of host applications. We find that existing ZNS designs exhibit (a) increased device-level write amplification (DLWA), (b) increased wear, and (c) increased interference with host I/O. We identify that (i) zone allocation granularity, (ii) zone geometry, (iii) write order, and (iv) zone mapping and management are the four main causes behind this.
To provide a predictable storage device, we propose SilentZNS, a new holistic zone management approach that expands the design space of zones and allocates blocks to zones on the fly, while minimizing wear, maintaining parallelism, and avoiding superfluous writes to the device. SilentZNS is a flexible zone allocation scheme that departs from traditional logical-to-physical zone mapping and allows arbitrary collections of blocks to be assigned to a zone. SilentZNS uses wear-aware allocation and maintains competitive read latency, while substantially reducing DLWA. We implement SilentZNS using the state-of-the-art ConfZNS++ emulator and evaluate it on synthetic microbenchmarks and a key-value storage engine. We show that SilentZNS reduces DLWA by 92% at a 10% zone occupancy threshold, reduces wear by 12%, and achieves up to 3.7× faster workload execution.

Key-value stores are widely adopted as the storage engine for modern applications, as they offer high throughput for writes, support for heterogeneous workloads, and are easily tunable. Given the large number of key-value stores available and their performance variability with workload shifts, finding the suitable data store and tuning for a specific use case often entails extensive benchmarking and analysis. State-of-the-art key-value benchmarks, such as YCSB, db_bench, and KVBench, however, are unable to capture several key characteristics of modern application workloads, including dynamically shifting workload characteristics, data with varied degrees of sortedness, or application-specific data formats. Further, existing benchmarks do not provide a unified interface to benchmark and compare multiple databases against the same workload.
We present TexBench, a unified key-value benchmarking suite that enables benchmarking key-value stores against dynamically shifting and production-like workloads and comparing their performance side by side. TexBench is built on top of Tectonic, a highly configurable, Rust-based key-value workload generator that can generate multi-phased shifting workloads and supports a rich set of operations, operation-specific distributions, variable data sortedness, and custom data formats. TexBench’s unified framework also allows users to benchmark multiple databases and perform an apples-to-apples comparison under the same workload readily within a single interface. Lastly, we augment TexBench with an LLM core that allows users to describe a workload in natural language, have that translated into a custom key-value workload, and benchmark and compare multiple databases against it in parallel.

Log-Structured Merge (LSM)-based storage engines offer high write throughput by storing the data on storage as immutable files that are opportunistically reorganized through compactions. Immutability of the files and their frequent garbage collection (GC), however, leads to a major performance bottleneck: high write amplification. This is further exacerbated by the device-level GC when LSM engines run on top of ZNS SSDs. While prior research has shown that compaction-aware file placement at the device level can reduce the overall write amplification, we point out that the proposed solutions are tuned exclusively for specific compaction strategies, SSD configurations, and workloads.
In this early-stage work, we highlight that for LSM engines on ZNS SSDs, performance is governed by a critical four-way trade-off between the compaction file picking policy (LSM-side) and the file placement, GC, and new zone allocation policies (ZNS-side). To this end, we introduce ZARC, a novel framework for Zone Allocation & Reclamation after Compaction that offers a continuum of hy- brid file placement policies to bring the overall write amplification closer to its theoretical lower bound and allows the user to navi- gate this vast design space for a given workload and configuration. ZARC’s hybrid file placement policies optimize performance for each LSM-level independently, leading to level-specific file placement, garbage collection, and zone allocation policies. Preliminary results from experimentation on ZenFS, a RocksDB file system for ZNS SSDs, show that ZARC’s hybrid file placement policies reduce data movement by up to 86% and ZARC-GC improves ZenFS garbage col- lection performance by (i) reclaiming sufficient free space and (ii) maintaining a small reserve of empty zones to prevent GC-induced stalls, and (iii) reducing GC-induced data movement by 8.6%.

Log-structured merge (LSM) trees are widely used in the storage layer of modern ingestion-optimized data stores. The high ingestion throughput, however, comes at the cost of sub-optimal range query (RQ) performance. This is because LSM-trees arrange the data as a hierarchical collection of sorted runs, which implies that every RQ must (i) probe all sorted runs to locate the qualifying entries, (ii) scan and merge the entries from all qualifying runs, (iii) filter out the logically invalidated entries by updates and deletes on the fly, and (iv) return the most recent version of each qualifying key. This leads to high read amplification and significant redundant work in terms of superfluous I/Os to storage and wasted CPU cycles, which is exacerbated in the presence of updates and deletes. Additionally, during compactions, the same data is read and written multiple times, further amplifying the read and write amplification.
In this paper, we introduce RangeReduce, an RQ-optimized LSM-engine that uses RQs as a hint to compact data that is already read into memory as part of the query, and thereby, improves the overall performance of the storage engine. The key intuition is to take advantage of the I/Os and CPU cycles spent on reading and merging data from slow storage during RQs and write the RQ-qualifying data back as part of a single sorted run. Such RQ-driven compactions enable RangeReduce to (i) read less data from fewer sorted runs for subsequent RQs, (ii) reduce overall data movement (reads and writes) due to RQs and compactions, and (iii) improve space amplification, while (iv) significantly reducing compaction debt. Experiments show that RangeReduce offers up to 90% lower compaction debt, 12% less data movement, and 20% lower space amplification while improving average RQ latency by up to 18%.

Search trees, like B⁺-trees, are often used as index structures in data systems to improve query performance at the cost of index construction and maintenance. For state-of-the-art B⁺-tree designs used in commercial data systems, this cost is negligible if the data arrives as fully sorted on the index attribute. Further, production systems employ a fast-path ingestion technique for B⁺-trees that directly appends the incoming entries to the tail leaf if the data is fully sorted, drastically reducing the index construction cost. However, this is only effective if the incoming data arrives fully sorted or with an extremely small number of out-of-order entries. In addition, the state-of-the-art sortedness-aware design (SWARE) navigates a tradeoff between reads and writes by buffering incoming data to absorb near-sortedness, which comes at the cost of slower query performance and increased overall design complexity.
To address these challenges, we present Quick Insertion Tree (QuIT), a sortedness-aware indexing data structure that improves ingestion performance with minimal design complexity and no read overhead. QuIT maintains in memory a pointer to the predicted ordered-leaf (pole) that provides a sortedness-aware fast-path optimization, and facilitates faster index ingestion. The key benefit comes from accurately predicting pole throughout data ingestion. Further, QuIT achieves high memory utilization by maintaining tightly packed leaf nodes when the ingested data arrives as near-sorted. This, in turn, helps improve performance during range lookups. Overall, we demonstrate that QuIT outperforms B⁺-tree (SWARE) by up to 3× (2×) for ingestion, while maintaining the same point lookup performance (up to 1.23× faster). QuIT also accesses up to 2× fewer leaf nodes than the B⁺-tree during range lookups.

Indexing in modern data systems facilitates efficient query processing when the selection predicate is on an indexed key. As new data is ingested, indexes are gradually populated with incoming entries. In that respect, indexing can be perceived as the process of adding structure to incoming, otherwise unsorted data. Adding structure, however, comes at a cost. Instead of simply appending the incoming entries, we insert them into the index. If the ingestion order matches the indexed attribute order, the ingestion cost is entirely redundant and can be avoided altogether (e.g., via bulk loading in a B⁺-tree). However, classical tree index designs do not benefit when incoming data comes with an implicit ordering that is close to being sorted, but not fully sorted.
In this paper, we study how indexes can exploit near-sortedness. Particularly, we identify sortedness as a resource that can accelerate index ingestion. We propose a new sortedness-aware (SWARE) design paradigm that combines opportunistic bulk loading, index appends, variable node fill and split factors, and an intelligent buffering scheme, to optimize ingestion and read queries in a tree index in the presence of near-sortedness. We apply SWARE to two state-of-the-art search trees (B⁺-tree and B^ε-tree), and we demonstrate that their Sortedness-Aware counterparts (SA B⁺-tree and SA B^ε-tree) outperform their respective baselines by up to 8.8× (SA B⁺-tree) and 7.8× (SA B^ε-tree) for a write-heavy workload in the presence of data sortedness, while offering competitive read performance, leading to overall benefits between 1.3×-5× for mixed read/write workloads with near-sorted data. Overall, we highlight that SWARE can be applied to other tree-like data structures to accelerate index ingestion and improve their performance in the presence of data sortedness.

Log-structured merge (LSM) trees have emerged as one of the most commonly used storage-based data structures in modern data systems as they offer high throughput for writes and good utilization of storage space. However, LSM-trees were not originally designed to facilitate efficient reads. Thus, state-of-the-art LSM engines employ numerous optimization techniques to make reads efficient. The goal of this tutorial is to present the fundamental principles of the LSM paradigm along with the various optimization techniques and hybrid designs adopted by LSM engines to accelerate reads.
Toward this, we first discuss the basic LSM operations and their access patterns. We then discuss techniques and designs that optimize point and range lookups in LSM-trees: (i) index and (ii) filter data structures, (iii) caching, and (iv) read- friendly data layouts. Next, we present the performance tradeoff between writes and reads, outlining the rich design space of the LSM paradigm and how one can navigate it to improve query performance. We conclude by discussing practical problems and open research challenges. This will be a 1.5-hour tutorial.

Log-structured merge (LSM) trees are widely used as the storage layer of production NoSQL data stores, as they offer efficient ingestion performance. To enable competitive read performance and reduce space amplification, LSM-trees periodically re-organize data layout on disk iteratively, through compactions. Compactions are at the heart of every LSM-based storage engine, fundamentally influencing their performance in terms of write amplification, write throughput, point and range lookup performance, space amplification, and delete performance. However, the process of compaction in LSM-engines is often treated as a black-box that is rarely exposed as a tuning knob. In this paper, we demonstrate Compactionary, a dictionary for LSM compactions, outlining the implications of compactions on performance, and how different LSM tunings and workloads influence compactions.
Compactionary breaks down the LSM compaction black-box, expressing compactions as an ensemble of four first-order design choices: (i) when to compact, (ii) how to organize the data after compaction, (iii) how much data to compact, and (iv) which data to compact. We configure Compactionary to demonstrate the operational flow of a family of state-of-the-art LSM compaction strategies and how each strategy influences the performance of the storage engine. The participants can (i) customize the workload, (ii) configure the LSM tuning, and (iii) switch between advanced compaction options, to understand individually the impacts of the different factors on performance. Further, to engage the interested participants, we extend the demonstration by allowing the participants (i) to create custom hybrid compaction strategies, as well as (ii) to configure the settings separately for each strategy in an individual analysis phase. The demo is available at https://disc-projects.bu.edu/compactionary/#interactiveDemo.

Log-structured merge (LSM) trees have emerged as one of the most commonly used disk-based data structures in modern data systems. LSM-trees employ out-of-place ingestion to support high throughput for writes, while their immutable file structure allows for good utilization of disk space. Thus, the log-structured paradigm has been widely adopted in state-of-the-art NoSQL, relational, spatial, and time-series data systems. However, despite their popularity, there is a lack of pedagogical textbook-like material on LSM designs. The goal of this tutorial is to present the fundamental principles of the LSM paradigm along with a digest of optimizations and new designs proposed in recent research and adopted by modern LSM engines. This will serve as introductory material for non-experts, and as a roadmap to cutting-edge LSM results for the LSM-aware researchers and practitioners.
Toward this, we first discuss in detail the basic operations (inserts, updates, deletes, point and range queries), their access patterns and their paths through the LSM data structure. We then dive into the details of recent research on optimizing each of those operations. We first discuss techniques and designs that optimize data ingestion, and then, we discuss new data structures that optimize read queries. Finally, we present the rich design space of the log-structured paradigm and outline how to navigate it and tune LSM-based systems. We conclude with a discussion on open challenges on LSM systems. This will be a 1.5-hour tutorial.

Log-structured merge (LSM) trees offer efficient ingestion by appending incoming data, and thus, are widely used as the storage layer of production NoSQL data stores. To enable competitive read performance, LSM-trees periodically re-organize data to form a tree with levels of exponentially increasing capacity, through iterative compactions. Compactions fundamentally influence the performance of an LSM-engine in terms of write amplification, write throughput, point and range lookup performance, space amplification, and delete performance. Hence, choosing the appropriate compaction strategy is crucial and, at the same time, hard as the LSM compaction design space is vast, largely unexplored, and has not been formally defined in the literature. As a result, most LSM-based engines use a fixed compaction strategy, typically hand-picked by an engineer, which decides how and when to compact data.
In this paper, we present the design space of LSM-compactions, and evaluate state-of-the-art compaction strategies with respect to key performance metrics. Toward this goal, our first contribution is to introduce a set of four design primitives that can formally define any compaction strategy: (i) the compaction trigger, (ii) the data layout, (iii) the compaction granularity, and (iv) the data movement policy. Together, these primitives can synthesize both existing and completely new compaction strategies. Our second contribution is to experimentally analyze 10 compaction strategies. We present 12 observations and 7 high-level takeaway messages, which show how LSM systems can navigate the compaction design space.

Data-intensive applications fueled the evolution of log structured merge (LSM) based key-value engines that employ the out-of-place paradigm to support high ingestion rates with low read/write interference. These benefits, however, come at the cost of treating deletes as a second-class citizen. A delete inserts a tombstone that invalidates older instances of the deleted key. State-of-the-art LSM engines do not provide guarantees as to how fast a tombstone will propagate to persist the deletion. Further, LSM engines only support deletion on the sort key. To delete on another attribute (e.g., timestamp), the entire tree is read and re-written. We highlight that fast persistent deletion without affecting read performance is key to support: (i) streaming systems operating on a window of data, (ii) privacy with latency guarantees on the right-to-be-forgotten, and (iii) en masse cloud deployment of data systems that makes storage a precious resource.
To address these challenges, in this paper, we build a new key-value storage engine, Lethe, that uses a very small amount of additional metadata, a set of new delete-aware compaction policies, and a new physical data layout that weaves the sort and the delete key order. We show that Lethe supports any user-defined threshold for the delete persistence latency offering higher read throughput (1.17-1.4x) and lower space amplification (2.1-9.8x), with a modest increase in write amplification (between 4% and 25%). In addition, Lethe supports efficient range deletes on a secondary delete key by dropping entire data pages without sacrificing read performance nor employing a costly full tree merge.
